3 Ply / 5 Ply / 7 Ply Corrugated Cardboard Production line

Main Technical Parameter and Requirements of Production Line
1. Design Speed: 120m/min Economic speed of 3 Ply Plant 80m/min Economic speed of 5 Ply Plant
2. Working Width: 600mm – 1600mm
3. Flute Profile: As per customers requirement.
4. Size of Machine: 75 x 8.2 x 3.8 mtr (LxWxH).

Parts Provided by the Customers
1. Steam Heating System: Steam boiler of 4000Kg/hr; Pressure 1.4-1.6 Mps
2. Upper steam pipeline and air recycling drainage pipeline.
3. Compressed air pipeline and glue pipeline.
4. Source of power supply.
5. Base paper, Starch etc required for the trial of Plant.
6. Machine oil, Lubricating hydraulic oil, Lubricating grease and high temperature grease.
7. Providing accommodation for the installation and debugging people.
