Chain Feeding Rotary Die Cutting Machine

  • Chain-feeding rotaty die-cutting machine.
  • Whole machine adopts chain feeding system
  • Roll adopts high quality steel, balance & hard chrome plated
  • Softcoat automatic repair structure, could be repair 3-4 times, improve rubbermat work-life.
  • Rubbermat adopts imported high quality product (Taiwan products or USA), cutting time could be 8 million to 10 million times.
  • Whole machine adopts electric, pneumatic, hudraulic part combination control, safe & high active, could be slit, cutting corner & creasing, one time for finish box.
  • Linear speed automatic compensate when soft roller diameter change, linear speed automatic compensate, make sure high precision in manufacturing.
  • Upper soft roll adpots mechanical type or hydraulic to control horizontal micro-swing area within 40 cm, to relieve wear & not influence die-cutting precision.
  • Die-cutting plate phase adopts planetray gear structure, 360 degree electric adjustment (running & stop all could be digit control).
Technology Parameter
Max. Coverage size mm 1500 x 2400 1500 x 2400 1270 x 2400 1270 x 2000
Max. die-cutter area mm 1400 x 2200 1400 x 1800 1200 x 2200 1200 x 1800
Max. mechanical speed pieces / min 60 60 115 115
Hight of die-cutter mm 25.4 25.4 25.4 25.4
Power of main motor kw 5.0 5.0 7.5 7.5
  Chain Feeding Rotary Die-cutting Machine
  Please Click on Photo to Zoom
